Description
SC5000-HitSAC is new generation of high temperature silicone adhesive coatings. It is optically clear resin and flexible until designed for high temperature applications. Call or e-mail SC5000 SDS EN v1.0_09.24for price.
Key Properties:
•High Temp Resistance
•Excellent Flexibility
•Extremely Adhesive
•Visually Transparent
Typical Resin Properties:
Resin type: 2 part
Density (after cure): 1.1 g/ml
Pot life @ RT: 12 hr
Viscosity (after mixing @25°C): ~200 mPa s
Appearance (post cure): Transparent/soft
Glass Transition: 53 °C
Storage Modulus: 123 MPa @25°C
Elongation @ Break: 100-120 %
Stress @ Break: 200-500 kPa
Young’s Modulus: 640-900 kPa
Shore A: 62
Temp.Stability: 96% mass retained @400°C (1hr)
Uncured Shelf Life: 1 year
Catalyst: Pt
Gel time: 45-60 min at 60˚C with 0.2 wt% catalyst load
Viscosity: 100 cps
Shelf life (w/o catalyst): 24-36 months
Heat distortion temperature: >1,100˚F (600˚C)
Flexural Strength at 23˚C: 13,513 psi / 67,200 psi
Flexural Modulus at 23˚C: 1.4 x 105 psi
Elongation: 3.5% / 1.7%
